Manual Clamping
CAD
Download
Product Details
Unit View:
Maximum Holding Capacity (lbf)
600.0
Weight (lb)
1.32
Vertical clamp stroke (in)
0.63
Height Under Clamp Arm (in)
2.19
Clamp Arm Length (in)
2.0
exerting_force_lbf_english
323.0
Vertical clamp stroke (in)
0.63
Stroke during rotation (in)
0.87
Exerting Force (lbf)
323.0
Stroke during rotation (in)
0.87
Stroke during rotation (mm)
22.0
Vertical clamp stroke (mm)
16.0
Max Clamping Stroke (mm)
16.0
Stroke during rotation (mm)
22.0
Exerting Force (N)
1437.0
Vertical clamp stroke (mm)
16.0
Maxmum Holding Capacity (N)
2670.0
Height Under Clamp Arm (mm)
55.7
Clamp Arm Length (mm)
50.8
Weight (kg)
0.6
exerting_force_n_metric
1437.0
cad_url_button
https://qa.product-config.net/catalog3/d/destaco/?cid=catalog&c=products&id=6004-SWR
DistributorGroup
Workholding (Manual, Power and Hydraulic Clamps)
Product Function
Clamping
Product Series
6004
PublishedDate
1723053580000
