WELDABLE, VERTICAL HOLD-DOWN CLAMPS FOR HEAVY DUTY APPLICATIONS – 500 SERIES
Visit Product Series:
Hold Down Clamps-500Unit View
Dimensions / Applications
- Length (in)3.08
- Weight (lb)1.76
- Application - AssemblyExcellent/High
- Application - Checking FixturesFair/Medium
- Application - Food ProcessingNot Recommended
- Application - MachiningFair/Medium
- Application - WeldingExcellent/High
- Duty Cycle3
- Product ApplicationCLAMPING
- Service EnvironmentHarsh/Dirty
Technical Details
- Clamp Arm Length (in)0.53
- Height To Top Of Clamp Arm (in)99.5
- Maximum Holding Capacity (lbf)1500.0
- Supplied?No
Product Information
- Accomodates Workpiece VariationNo
- Base Mounting StyleLong
- BrandDESTACO
- Clamp Arm StyleWeldable
- HandleVertical
- Handle ColorRed
- Product TypeVertical Hold-Down Toggle Clamp
- Spindle Included?No
- Standard MaterialForged alloy steel
