Manual Clamps with Front Mount Base

225-UF - Front Mount, U-Bar

Visit Product Series:

Hold Down Clamps-225Front Mount Base

Unit View

Dimensions / Applications

  • Length (in)6.91
  • Weight (lb)0.55
  • Application - AssemblyExcellent/High
  • Application - Checking FixturesExcellent/High
  • Application - Food ProcessingFair/Medium
  • Application - MachiningPoor/Low
  • Application - WeldingFair/Medium
  • Duty Cycle2
  • Product ApplicationCLAMPING
  • Service EnvironmentNormal

Technical Details

  • Clamp Arm Length (in)2.69
  • Height Under Clamp Arm (in)1.31
  • Maximum Holding Capacity (lbf)500.0
  • Supplied?No

Product Information

  • Accessories215208-M|507107|207426-Q
  • Accomodates Workpiece VariationNo
  • Base Mounting StyleFront Mount Base
  • BrandDESTACO
  • Clamp Arm StyleU-Bar
  • HandleHorizontal
  • Handle ColorRed
  • Product TypeHorizontal Hold-Down Toggle Clamp
  • Spindle Assembly215208-M
  • Spindle Included?No
