Hold Down Clamps

DESTACO’s 227 Series horizontal hold down clamps feature a low profile design, availability in stainless steel models, and large handle clearance in the open position.

LOW-PROFILE, MANUAL HORIZONTAL HOLD DOWN CLAMPS – 227 SERIES

DESTACO’s 227 Series horizontal hold down clamps feature a low profile design, availability in stainless steel models, and large handle clearance in the open position. These clamps are used in assembly, fixture checking, woodworking, and closures.

Features

  • Holds up to 1,680 lbs (7.5 kN) capacity
  • Heavy Duty horizontal clamps with high strength and long life.
  • Low height design
  • Many equipped with DESTACO Toggle Lock Plus®, an innovative safety feature that adds a secondary lock to the clamp to help ensure that the over-center locking condition is maintained and protected against unintentional opening.
  • Low silhouette hold down clamp features a handle that can be operated from either side or from behind
  • Unique standard design gives greater hand clearance between the bar and handle, providing optimal overhead clearance.

Markets

Applications

  • Fixturing and Testing
Product
Short Description
Product Type
Standard Material
Base Mounting Style
Handle Color
Clamp Arm Length (in)
Handle
Maximum Holding Capacity (N)
Clamp Arm Style
Service Environment
Handle Opening (+10°)
Height Under Clamp Arm (in)
Maximum Holding Capacity (lbf)
Accomodates Workpiece Variation
Clamp Bar Opening (+10°) (degrees)
Weight (lbs)
227-U
Flanged Base, U-BarHorizontal Hold-Down Toggle ClampSteelFlangeRed2.65Horizontal2220U-BarNormal561.25500No910.68
227-U-B
Straight Base, U-barHorizontal Hold Down ClampSteelFlangeBlue2.65Horizontal2220U-BarNormal561.25500No910.68
227-U-G
227-U with Green HandleHorizontal Hold Down ClampSteelFlangeGreen2.65Horizontal2220U-BarNormal561.25500No910.68
227-U-K
227-U with Black HandleHorizontal Hold Down ClampSteelFlangeBlack2.65Horizontal2220U-BarNormal561.25500No910.68
227-U-L
Flanged Base, Open BarHorizontal Hold Down ClampSteelFlangeRed2.39Horizontal2220Open U-BarNormal561.25500No910.68
227-U-Y
227-U-Y - 227-U with Yellow HandleHorizontal Hold Down ClampSteelFlangeYellow2.65Horizontal2220U-BarNormal561.25500No910.68
227-UB
Straight Base, U-barHorizontal Hold Down ClampSteelStraightRed2.65Horizontal2220U-BarNormal561.45500No910.68
227-UB-L
Straight Base, Open BarHorizontal Hold Down ClampSteelStraightRed2.39Horizontal2220Open U-BarNormal561.45500No910.68
227-USS
227-USS - Stainless Steel 227-UHorizontal Hold Down ClampStainless SteelFlangeRed2.66Horizontal2670U-BarNormal561.28600No910.68
